Panasonic PT-MZ14KLWU7 14,000 Lumens, LCD, WUXGA Resolution (1,920 x 1,200) No Lens

Model: PT‑RZ14K 3‑Chip DLP™ Projector

Projector Type: 3‑Chip DLP™ projection system

Laser Light Source: Laser diode (SOLID SHINE LASER)

Weight: Approx. 35 kg (77.2 lbs)

Dimensions (W × H × D): Approx. 550 × 220 × 570 mm (21 5/8″ × 8 11/16″ × 22 7/16″)

Resolution: WUXGA (1920 × 1200 pixels)

Display Method: DLP™ chip × 3 (16:10 aspect)

Number of Pixels: 2,304,000 × 3

Brightness: 14,000 lumens (average), 14,700 lumens (center)

Contrast Ratio: Up to 25,000:1 (Dynamic Contrast, full On/Off)

Center‑to‑Corner Zone Ratio: ~90 %

Lens Shift (Powered): Vertical ±66 % / Horizontal ±24 % (varies by lens)

Screen Size (Diagonal): Approx. 1.78–25.40 m (70–1000 in); varies with lens choice

• Laser Lifetime: ~20,000 hours (Normal mode), ~24,000 hours (Eco mode) before 50 % brightness reduction
• Dust Protection: IP5X‑compliant optical engine and laser module for maintenance‑free operation
• Cooling: Filterless liquid cooling system

HDMI Inputs: HDMI × 2 (Deep Color, HDCP 2.3 compatible)

DisplayPort: DisplayPort × 1 (Deep Color, HDCP 2.3)

LAN: RJ‑45 network connection (PJLink® compatible)

BNC: Multi‑Projector Sync and 3D Sync inputs/outputs available

Serial Control: RS‑232C In/Out for external control

USB: USB Type‑A for power or optional wireless module/USB memory

Expansion Slot: SDM‑ready slot for function boards and optional connectivity upgrades

• Power Supply: AC 100–120 V and AC 200–240 V support
• Operating Power Consumption: Approx. 950 W (Normal), 780 W (Eco)
• Noise Level: Approx. 40 dB (Normal/Eco)
