Vizrt TCMINISSUB Vizrt TriCaster Mini S Software Subscription

TriCaster Mini S is Vizrt's first software-only TriCaster, running on your own hardware or a Vizrt-certified platform. It offers 8 live inputs, 4 M/Es, 2 DDR players, vertical sessions and up to 2160p/60, with Viz Flowics Go graphics and standard support included.

• 8 x total IP video inputs via NDI®, resolution-independent
• NDI inputs supporting video input in any combination of standard formats, resolutions, and frame rates1
• 2160p 59.94, 50, 29.97, 25
• 1080p: 59.94, 50, 29.97, 25
• 1080i: 59.94, 50
• 720p: 59.94, 50, 29.97, 25
• SD: 59.94, 50, 25
• 1 Available frame rates determined by session video standard (NTSC or PAL)

• Support for up to 8 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via serial and network protocols, including RS232, RS422, and IP, with integrated controls and preset system. Control connections will vary based on hardware

• Native support for up to 2 simultaneous Skype® video call inputs via Skype TX software integration, including tally and Talk Back communication

• IP video output via NDI, optionally configurable for:
• 4 x independent video mix outputs
• 1 x UHD video mix output

• 2 x resolution-independent streaming video outputs, independently configurable and controllable, with simultaneous stream archive

• UI and multiview outputs available via onboard GPU outputs

• 4 x M/E buses supporting video re-entry
• 1 x Mix/Effect channel per bus with support for up to 2 sources
• 4x channels NDI|HX 2 in HD H.264 or HEVC codec

• 2 x DSK channels

• 4 x media players
• 2 x DDR
• 1X GFX
• 1 x Sound
• 15 x media buffers
• 5 x animation buffers including GIF support
• 10 x graphic buffers

• Integrated LiveMatte™ chroma and luma keying technology on all source channels and M/E buses
• 8 x input keyers
• 2 x media player keyers
• 4 x M/E keyers
• 15 x buffer keyers

• Integrated video composition engine on the switcher and each M/E bus to create, store, and apply layer configurations and DVE-style motion sequences
• 16 x configurable COMP presets per bus

• Integrated LiveSet™ technology with 30+ live virtual sets and box effects included

• Integrated DataLink™ technology enables real-time, automated data input from internal and external sources, including webpages, spreadsheets, scoreboards, databases, RSS feeds, watch files, XML, CSV, ASCII, and more

• Record, store, edit and automate commands and user-configured operation sequences
• Attach to control panel buttons, keyboard shortcuts, hotspots, MIDI and X-keys® buttons or GPI triggers
• Attach to internal events and state changes, including audio, media playback, tally and specific switcher actions
• Supports control via web-based interface

• 4 x recording channels from either NDI® inputs or Mix outputs
• Records and retains alpha channel data
• 4 x QuickTime® archival video recorders (Native NDI Codec for recording) 2
• 2 QuickTime Player not required for playback in common NLE applications

• Integrated waveform and vectorscope, full field rate with digital calibration, color preview and support for ITU-R Rec. 709

• Grab full-resolution, deinterlaced still images from external video sources and outputs

• Export video and image files to social media, FTP, local or external volumes, and network servers, with optional transcoding

• Integrated multi-channel audio mixer with support for stereo audio, and DSPs

• Native support for network audio input and output via NDI®
• Embedded audio supported for all NDI® input and output video signals
• Integrated support3 for Dante™ networking protocol from Audinate®
• 3 Requires Dante Virtual Soundcard license from Audinate (sold separately)
• 5 Requires third-party virtual sound card license (sold separately)

• Import, store, and playback multimedia files, with optional transcoding, including:
• Video | AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM, and more
• Image | PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP, and more
• Audio | AIFF, MP3, WAV, and more

• Video | YCbCr + Alpha color space, using 4:2:2:4 Audio: Floating Point, 96 kHz

• Processing Latency | ~1.0-1.5 frames

• Support for network tally via NDI®

• Support for standard MIDI protocol enabling third-party device control

• 2 Users
• 2GB Asset Library
• 1 Output
• 1 Team
• Graphics Editor
• Timeline-based Animations
• Text Crawler
• Assets Library
• 140 ready-to-use free graphics
• Data Integrations
• Google Sheets Data Provider
• RSS / Atom Data Provider
• JSON REST Connector
• JSON WebSocket Connector
• Security – MFA
• Control API
• Knowledge Base Support
• Powered by Viz Flowics running in cloud, rendered locally via TriCaster Live Link

Source: vizrt.com technical specifications, retrieved 2026-10-27. Subject to change without notice.
