16 × simultaneous external video inputs (up to 4K UHD, up to 60fps / 2160p 59.94)
Network video input: 16 × IP video inputs via NDI, resolution-independent, supports key/fill
SDI video input: 4 × 3G/HD/SD-SDI (formats include 1080p/i, 720p, 576i, 480i)
PTZ support for up to 8 simultaneous PTZ cameras via RS232/RS422/IP with presets
Up to 4 independent video mix outputs, delivered simultaneously via IP and SDI
Network video output (NDI): configurable for 4 × independent mixes or 1 × 4K UHD mix
SDI video output: 4 × 3G/HD/SD-SDI; configurable for 4 × mixes or 1 × 4K UHD via quad-link grouping
Stream output: 2 × streaming outputs (resolution-independent), independently configurable, with simultaneous stream archive
Multiviewer output: 3 outputs (DVI UI+multiviewer, HDMI multiviewer, DisplayPort multiviewer)
5 × media players (2 DDR, 2 GFX, 1 Sound)
15 × media buffers (10 animation, 5 graphic)
LiveMatte chroma/luma keying; keyers: 16 input, 4 media player, 4 M/E, 1 PREVIZ, 15 buffer
16 × COMP presets per bus; LiveSet virtual sets (30+ included); DataLink; macro system with triggers and web control
Recording: 6 configurable video recording channels (IsoCorder), plus QuickTime archival + H.264 distribution recorders + MP3 audio recorder (as listed)
Storage: 2 × 3TB internal drives; external recording via USB 3.0 / eSATA; shared storage integration supported
Integrated audio mixer (DSP) with 4×4×4 audio input routing; embedded SDI audio; balanced XLR and 1/4" line I/O; NDI network audio; optional Dante/AES67
Throughput latency: ~1.0–1.5 frames
Genlock input (SD bi-level / HD tri-level reference)
Chassis: 2RU, 400W PSU; dimensions (with rack ears) 19.0 × 3.5 × 19.57 in (48.3 × 8.9 × 49.7 cm)
