Perfect for high-impact game-day shows with fewer inputs, but multiple mixed effects. Offers simultaneous independent control, and great for teams that prefer working with a joystick. Produce like the pros and teach with real world tools. Students learn and grow with hands-on experience using professional production tools. Create a stadium experience that your team will appreciate, and awe fans.
- External Video Inputs: 16 simultaneous inputs supporting sources up to 4K UHD at 60fps (2160p 59.94).
- Network Video Input: 16 x resolution-independent IP inputs via NDI™ with full support for key and fill.
- SDI Connectivity: 4 x 3G/HD/SD-SDI inputs; optionally supports up to 16 SDI inputs or quad-link 4K UHD via network conversion modules.
- Mix/Effects (M/E): 4 x M/E buses supporting video re-entry, 4 KEY layers per bus, and 9 memory slots per bus.
- Outputs: Configurable for up to 4 independent video mix outputs (SDI and IP); 3 x streaming video outputs; 3 x multiviewer outputs (DisplayPort/HDMI).
- Instant Replay: Includes the Viz 3Play 3P1 system with its dedicated hardware control panel for instant highlights and multi-angle slow motion.
- Graphics Software: Includes Viz Flowics Basic (1-year license), featuring a cloud-native editor, data integrations (Google Sheets, RSS, JSON), and 140+ ready-to-use free graphics.
- Data Automation: DataLink™ technology for real-time automated data from scoreboards, spreadsheets, and databases.
- Media Players: 2 x DDR, 2 x GFX, 1 x Sound, plus 15 media buffers (10 animation, 5 graphic).
- Integrated Mixer: Multi-channel audio mixer with support for quad-channel audio and 96 kHz floating-point processing.
- Local I/O: 1 x Balanced XLR stereo pair (Line), 3 x Balanced 1/4” stereo pairs (Line), and 4 x SDI embedded inputs.
- Network Audio: Native support for NDI audio; integrated support for Dante™ and AES67 (requires optional virtual sound card licenses).
- PTZ Control: Support for up to 16 simultaneous Pan-Tilt-Zoom (PTZ) robotic cameras via RS232, RS422, and IP.
- Internal Storage: 2 x 2TB internal media drives (4TB total).
- System Drive: 250GB SSD.
- NICs: 1 x 10 Gigabit LAN, 1 x 2.5 Gigabit LAN, and 1 x 1 Gigabit LAN.
- Recording: 16 configurable recording channels (NDI, QuickTime, H.264) and 1 x MP3 audio recorder.
- Chassis: 2RU chassis (19.0 x 3.5 x 19.57 in) with 500W PSU.
