16 × simultaneous external video inputs supporting any mix of sources up to 4K UHD at 60 fps (2160p 59.94).
Network Video Input: 16 × IP video inputs via NDI® with resolution-independent support including key & fill.
SDI Video Inputs: 4 × 3G/HD/SD-SDI connections supporting a wide range of standard formats/resolutions:
- 1080p: 59.94, 50, 29.97, 25
- 1080i: 59.94, 50
- 720p: 59.94, 50, 29.97, 25
- 576i: 50
- 480i: 59.94
Supports up to 16 simultaneous PTZ robotic cameras via serial (RS-232/RS-422) and IP control with integrated preset system.
-
Mix Outputs: Configurable for up to 4 independent video mix outputs with simultaneous delivery via IP and SDI.
-
Network Output: IP video output via NDI®, configurable for:
- • 4 × independent video mix outputs
- • 1 × 4K UHD video mix output.
- SDI Video Output:
- • 4 × 3G/HD/SD-SDI connections, optionally configurable for 4 HD outputs or 1 4K-via-quad-link output.
Mix/Effect (M/E) Buses: 4 × M/E buses supporting video re-entry.
• Each bus: 1 × mix/effect channel, up to 4 sources.
• 4 × key layers per bus.
• 9 × memory slots per bus + PREVIZ bus.
-
Media Players: 5 (2 DDR, 2 GFX, 1 Sound).
-
Media Buffers: 15 total (10 × animation, 5 × graphic).
-
Clip Players: 30 (usable for transitions or media).
• Integrated LiveMatte™ chroma & luma keying on all source channels + M/E buses.
• 16 × input keyers, 4 × media keyers, 4 × M/E keyers, 1 × PREVIZ keyer, 15 × buffer keyers.
COMPs: 16 × configurable composition presets per bus.
Virtual Sets: LiveSet™ integrated with 30+ live virtual sets and effects.
DataLink™: Supports real-time automated data inputs
• 16 × configurable video recording channels.
• 4 × QuickTime® archival recorders.
• 3 × H.264 distribution recorders.
• 1 × MP3 audio recorder.
Internal Storage: 2 × 2 TB media drives (configurable).
