Scalable, high-input production platform for larger venues with graphics and replays for key moments during the game. Produce like the pros and teach with real world tools. Students learn and grow with hands-on experience using professional production tools. Create a stadium experience that your team will appreciate, and awe fans.
- External Video Inputs: 44 simultaneous external video inputs, supporting combinations of sources up to UHD at 60fps (2160p 59.94).
- Network Video Input: 44 x IP inputs via NDI®, resolution-independent, with support for key and fill.
- Video Outputs: Configurable for up to 8 independent HD or 2 UHD video mix outputs via IP and SDI.
- Network Video Output: 56 x IP outputs via NDI® (HD sessions only).
- M/Es: 8 x configurable M/E channels for advanced layering and effects.
- Integrated Mixer: 44-channel digital audio mixer with 8-channel audio support, DSPs, and 4x8x8 routing.
- Network Audio: Native support for NDI® audio; integrated support for Dante™ (requires license) and AES67.
- Media Players: 5 total (4 x DDR, 1 x Sound) plus 15 media buffers (10 animation, 5 graphic).
- Audio Processing: Floating Point, 96 kHz.
- Recording Capacity: 8 x M/E channels, up to 16 physical SDI inputs, 4 x DDRs, and 3 x streaming encoders.
- Internal Storage: 4 TB SSD.
- System Drive: 500 GB SSD.
- External Connectivity: 7 x USB 3.2 Type A, 1 x USB 3.2 Type C, 1 x USB 2.0.
- Graphics Software: Includes Viz Flowics Basic (3-year license) with a 5GB asset library and cloud-based control.
- Replay System: Includes Viz 3Play 3P1 for instant highlights and replays.
- Virtual Sets: LiveSet™ technology with 30+ built-in virtual sets.
- Keying: LiveMatte™ chroma/luma keying on all 44 inputs, media players, and M/Es.
- Data Integration: DataLink™ for real-time automated data from scoreboards, RSS, spreadsheets, etc.
- Chassis: Tower chassis (17.5" x 15.2" x 6.65") with 1 x 1125W PSU.
- Weight: 27.8 lb (12.6 kg).
- Networking: 1 x 10 GbE and 1 x 1 Gigabit NIC.
