Yamaha RIVAGE PM3 CS-R3 Compact Control Surface - 38-Fader, 15-inch Touch Panel

YAM-CSR3 The CS-R3 offers a simplified single-display interface with 38 physical faders and full RIVAGE sound quality. It is optimized for venues requiring the RIVAGE processing quality but with fewer hardware controls.

Faders: 38 motorized faders (12 + 12 + 12 + 2).

Display: 1 × 15″ touch-panel display.

Selected Channel Section: Direct access to Dynamics, GAIN, HPF, EQ, PAN, Function parameters via encoders.

Custom Fader Banks: Yes (6 × 5 per bay).

User Defined Keys: 12 × 4 banks.

User Defined Knobs: 1 (assignable across 4 × 4 banks).

Analog I/O: 8 inputs / 8 outputs.

Slots: 2 × MY expansion slots.

GPI / MIDI I/O: 8 GPI in / 8 GPI out, MIDI In/Out.

USB Ports: 5 USB ports (1 supports 2-track USB recording).

Dimensions (W × H × D): 1,145 × 385 × 650 mm (45.1″ × 15.2″ × 25.6″).

Net Weight: 38 kg (83.8 lbs).

Power Supply: Dual redundant built-in PSU.

Power Consumption: ~200 W.
